Understanding Spanning Tree Options in Aruba CX Switches

Joe Gehrke

Oct 3 2025

3 min read

In enterprise networks, Layer 2 redundancy is essential, but it introduces the risk of loops. Aruba CX switches support two primary Spanning Tree Protocol (STP) options to prevent loops while maintaining high availability:

Multiple Spanning Tree Protocol (MSTP)
Rapid Per-VLAN Spanning Tree Plus (RPVST+)

Each protocol has its strengths depending on your network’s size, complexity, and design goals.

MSTP (Multiple Spanning Tree Protocol)

Multiple-Instance Spanning Tree Protocol (MSTP) ensures that only one active path exists between any two nodes in a spanning-tree instance. A spanning-tree instance comprises a unique set of VLANs, and belongs to a specific spanning-tree region. A region can comprise multiple spanning-tree instances (each with a different set of VLANs), and allows one active path among regions in a network.

When to Use MSTP:

You have many VLANs and want to optimize traffic paths.
You need to scale your Layer 2 topology.
You want to reduce CPU load by aggregating VLANs into fewer STP instances.

Configuration:

switch(config)# spanning-tree mode mstp switch(config)# spanning-tree

Most small to medium configurations can be finished here, but if you need to configure different instances for separate VLANs, then you can refer to creating “spanning-tree instance vlan” in HPE’s documentation located here.

Verification:

switch# show spanning-tree mstp

RPVST+ (Rapid Per-VLAN Spanning Tree Plus)

RPVST+ is Aruba’s implementation of Cisco’s Rapid PVST+, offering a separate spanning tree instance for each VLAN. This provides the highest level of traffic optimization and fault isolation but increases CPU and memory usage.

When to Use RPVST+:

You need per-VLAN path control.
You’re integrating with Cisco networks using PVST+/RPVST+.
You want fast convergence and VLAN-level fault isolation.

Configuration:

switch(config)# spanning-tree mode rpvst switch(config)# spanning-tree spanning-tree vlan “List all vlans”

Set the core switch as the root switch for all vlans.

spanning-tree vlan “list all vlans” priority 5

The default priority is 8, so any priority lower than that will make that switch the root for that VLAN, assuming no other switch has a priority set lower (via manual configuration).

Verification:

switch# show spanning-tree rpvst

Choosing the Right Mode

Protocol	Convergence	VLAN Control	Scalability	Use Case
MSTP	Fast	Grouped VLANs	High	Large, VLAN-rich networks
RPVST+	Fast	Per-VLAN	Medium	Cisco integration, VLAN-specific tuning

Conclusion

Aruba CX switches offer flexible STP options to meet diverse network needs. MSTP is ideal for scalability and efficient resource use, while RPVST+ provides granular VLAN control and compatibility with Cisco environments. Choosing the right protocol ensures a loop-free, resilient, and optimized Layer 2 topology.

Have any questions which option works best for your environment? Please reach out to our IT experts at any time!
